LINE LASER
TECHINCAL SPECIFICATIONS
Working range/with receiver
Self-levelling accuracy
Self-levelling range
Continuous working time
Operating temperature
Storage temperature
Relative humidity
Protection rating
Tripod mounting thread
Laser type
Power supply
Dimensions
Weight
* The operating range may differ from the declared depending on the
lighting conditions.
SET
Cross line laser – 1 pcs.
Carry bag – 1 pcs.
Batteries (АА) – 4 pcs.
User manual – 1 pc.
8
XLiner Duo/Combo 360
user manual
40 m/80 m*
±0,2 mm/m
± 3,5°
8 hours
-10°C ... +50°C
-20°C ... +70°C
90%
IP54
1/4'' and 5/8''
Class II 635 nm < 1 mW
4 х 1.5V LR6 alkaline (AA)
132x85x116 mm
0,44 kg
CROSS
EN
LINE LASER

OPERATION

Before start operation remove the battery cover, insert the batteries,
observing correct polarity. Put battery cover back.
Use AA alkaline batteries only, all batteries should be of the same type
and brand with the same charge level. Replace batteries if battery
charge level indicator starts flashing red while operation.
Place the laser level on a firm and stable surface or a tripod.
Move compensator lock to choose necessary operating mode:
1) Automatic levelling:
Move lever lock to ON position
Compensator is unlocked. Power indicator becomes red. If the laser
level is out of the range of automatic compensation laser lines flash.
Short press button to switch on necessary laser planes.
Short press button to switch on/off pulse mode that allows
working with laser receiver. In this mode pulse mode indicator will
turn red. To switch the laser level off move compensator lock to locked
position .
2) Locked compensator, to build inclined planes and lines:
Move compensator lock to OFF position
Power indicator becomes red. Press and hold button
during 3 seconds to switch the laser level on.
Short press button
Activated laser lines flash every 5 seconds in this mode.
XLiner Duo/Combo 360
user manual
.
. Compensator is locked.
to switch on necessary laser planes.
