Table of contents
1 Safety notes 15
1.1 Regulations/Guidelines 15
1.2 Intended use 16
1.3 Initial start-up 16
1.4 Working on the system 16
1.5 Liability 16
2 Technical Data 17
3 Installation 19
3.1 Wall-mounted installation 19
3.2 Shut-off fittings 19
3.3 Changing thermometers 20
3.4 Safety valve 21
3.5 Backflow preventer 21
3.6 Connecting an expansion
vessel (provided on site) 22
3.7 Heat transfer medium 22
4 Pressure Test, Filling and
Flushing the System
4.1 Leak test 22
4.2 Flushing and filling 23
4.3 Venting 23
4.4 Draining 24
5 Versions 24
14
Solar circuit control
Please note: The installation and operating
instructions for the controller model are
enclosed separately.
Effiziente Energietechnik
Safety notes
1.
Read through these instructions carefully before installation.
The complete station may be installed and initially started up by an approved, qualified firm only.
Familiarise yourself with all the parts and their handling
before starting the work.
- Read the assembly instructions
before use
- Risk of cutting
- Risk of crushing
1.1 Safety notes
Note and observe the accident prevention regulations/health & safety regulations, the environmental regulations
and the statutory regulations for assembly, installation and operation. Furthermore, the relevant guidelines of the
DIN, EN, DVGW, VDI and VDE (incl. lightning protection) as well as all relevant country-specific standards, laws
and guidelines.
Electrical connection:
Electrical connection work may only be carried out by
qualified electricians. The VDE guidelines and regulations of the electrical utility company responsible must all be
complied with.
Extract:
Thermal solar systems and their components:
DIN EN 12975 Solar collectors
DIN EN 12976 Prefabricated systems
DIN EN 12977 Custom built systems
Electrical connection:
VDE 0100: Construction of electrical equipment,
earthing, protective conductors,
equipotential conductors.
VDE 0185: General information for the installation of lightning protection systems.
VDE 0190: Main equipotential bonding of electrical systems.
Additional guidelines and notes:
VDI 6002 Part 1 General principles, systems engineering and use in housing
VDI 6002 Part 2 Uses in student hostels, retirement homes, hospitals, indoor swimming
pools and on camping sites
