4. Pressure Test, Filling and Flushing the System
4.4 Entleeren
When draining the system, be sure the handle of the forward flow ball valve is set to 45° before the forward
flow side is drained at the lowest point. In this position, the non-return valve is open. The return flow side
has to be drained both at the lowest point in the pipework circulation system and at the safty set
with the drain valve. When water is used, be sure the pipeline system is completely drained.
The heat transfer fluid should be collected in a suitable container
and disposed of according to the manufacturer's instructions in an environmentally
sound manner.
Note: The system is usually under pressure. Danger of scalding!

5. Versions

Please refer to the current price list for prices.
1 - branch
Type:
without pump
with Grundfos Solar 15-65
with Grundfos Solar 15-85 - PWM signal
with Wilo Star-ST 15/6
with Wilo Stratos-PARA 15/1-7 - 0-10 V signal
with Wilo Stratos-PARA 15/1-7 - PWM signal
As above but with integrated Basic Pro controller
Digital differential temperature controller for thermal solar systems
(1x collector array, 1x accumulator); full graphic backlit black/white display, operation via rotary/push control and
ESC-button; 3 inputs for PT 1000 sensor, analog or PWM output for high-efficiency pump, speed regulation,
pre-configured hydraulics diagram, Triac output, error monitoring, manual operation option, collector safety function,
recool function, start-up/service assistant, fixed T and Delta T regulation, tube collector function, shut-off delay for
outputs, antifreeze, sensor monitoring, monitoring of output parameters, operating hours counter for outputs, solar
yield measurement for pump control including data output, yield recording without volumetric flow meter option,
scope of delivery including 2x PT 1000 universal temperature sensors
Type:
without pump
with Grundfos-pump Solar 15-65
with Grundfos pump Solar 15-85 - PWM Signal
with Wilo-pump Star-ST 15/6
with Wilo-pump Stratos-Para 15/1-7
with Wilo Stratos-Para 15/1-7 - PWM Signal
The pump manufacturer's installation and assembly instructions must be observed.
Accessories for connecting an auxiliary vessel or 2 solar stations, e.g., for east-west installations,
are available in the current price list.
24
Art° N°
45719.2 EA
45719.2
45719.4
45719.2 WI
45719.3 WI
45719.4 WI
Art° N°
45719.24 EA
45719.24
45719.44
45719.24 WI
45719.34 WI
45719.44 WI
Effiziente Energietechnik
5. Versions
Please refer to the current price list for prices.
2 - branch
without controller, without permanent venter
without pump
with Grundfos-pump Solar 15-65
with Grundfos-pump Solar 15-85 PWM Signal
with Wilo-pump Star-ST 15/6
with Wilo-pump Stratos-Para 15/1-7-0-10 V Signal
with Wilo-pump Stratos-Para 15/1-7 - PWM Signal
without controller, without permanent venter
without pump
with Grundfos-pump Solar 15-65
with Grundfos-pump Solar 15-85 PWM Signal
with Wilo-pump Star-ST 15/6
with Wilo-pump Stratos-Para 15/1-7-0-10 V Signal
with Wilo-pump Stratos-Para 15/1-7 - PWM Signal
with controller Basic Pro without permanent venter
without pump
with Grundfos-pump Solar 15-65
with Grundfos-pump Solar 15-85 PWM Signal
with Wilo-pump Star-ST 15/6
with Wilo-pump Stratos-Para 15/1-7-0-10 V Signal
with Wilo-pump Stratos-Para 15/1-7 - PWM Signal
with controller Basic Pro without permanent venter
without pump
with Grundfos-pump Solar 15-65
with Grundfos-pump Solar 15-85 PWM Signal
with Wilo-pump Star-ST 15/6
with Wilo-pump Stratos-Para 15/1-7-0-10 V Signal
with Wilo-pump Stratos-Para 15/1-7 - PWM Signal
The pump manufacturers' installation and assembly instructions must be noted and observed.
Effiziente Energietechnik
45705.2 EA
45705.2
45705.4
45705.2 WI
45705.3 WI
45705.4 WI
45705.6 EA
45705.6
45705.8
45705.6 WI
45705.7 WI
45705.8 WI
45705.24 EA
45705.24
45705.44
45705.24 WI
45705.34 WI
45705.44 WI
45705.64 EA
45705.64
45705.84
45705.64 WI
45705.74 WI
45705.84 WI
