Expolite Tour-PAR COB 200 Bedienungsanleitung Seite 21

Setting DMX-Address
MENU
Menu Mode PERSON
The DMX start address of the fixture is set in the menu Menu Mode, submenu Address. This is
retained even when changing the personality.
Setting DMX-Personality
MENU
Menu Mode
PERSON
The personality is set in the menu Menu Mode, submenu DMX Mode. There are five different modes
which can be chosen: 2Ch, 3Ch1, 3Ch2, 5Ch and 10Ch.
Activating Slave Mode
MENU
Menu Mode PERSON
In the menu Menu Mode, submenu Slave, the Slave mode of the fixture can be activated. In this
Mode the fixture can be controlled by a master unit of the same fixture type.
Stand-Alone Possibilities
MENU
Menu Mode PERSON
The TourPar COB 200 has several different possibilities of stand-alone usage:
Static: In the submenu Static a static scene for Stand-Alone use can be created. This is mixed using
the DMX value scale 0-255 for Dimmer, Strobe, Red, Green, Blue, White and Amber.
Color Macro: 15 preset colour macros can be chosen in the submenu Color Macro.
Auto: A preset automatic sequence which can be run in the submenu Auto.
PERSON Address HSIC 0 - 512
DMX Mode HSIC 2Ch
PERSON
DMX HSIC HSIC 3Ch1
HSIC 3Ch2
HSIC 5Ch
HSIC 10Ch
PERSON PERSON Slave RUN
PERSON Static Dimmer HSIC
Strobe
HSIC Red
HSIC Green
HSIC Blue
HSIC White
HSIC Amber
PERSON Macro Macro 1 HSIC
Macro 2 HSIC
o
o
o
Macro 15 HSIC
Jumping Jumping Speed
HSIC
PERSON
Jumping Strobe
HSIC
Fading Fading Speed
PERSON HSIC
Fading Strobe
HSIC
PERSON Auto Auto Mode HSIC
RUN DMX HSIC HSIC Sens
PERSON PERSON Sound
E-21
HSIC 0 - 255
HSIC 0 - 255
HSIC 0 - 255
HSIC 0 - 255
HSIC 0 - 255
HSIC 0 - 255
HSIC 0 - 255
HSIC 0 - 255
HSIC 0 - 255
HSIC 0 - 255
HSIC 0 - 255
HSIC 00 - 99
