Spare Parts - FAR RAC 180 Bedienungsanleitung

RAC 180
No. CODE Q.ty
2 712716 1 Cover
3 710300 1 O Ring 020
4A 710837 1 Screw stem
5 710920 1 O Ring 2-337
6 720815 1 Pneumatic piston
7A 710836 1 Flat washer
8 710860 1 Stem
9A 710829 1 Dampener
10 710915 1 O Ring 2/124 Parker
11 710931 1 O Ring 5/615 Parker
12 710856 1 Guide stem connector
13 710390 1 Balsele B075047
14 711827 1 Seal TS 12-19-5,7/L
15 710914 1 O Ring 2/116 Parker
17 710402 1 Seeger ring I22
18 710922 2 O Ring 018D
19 712268 1 Spring guide plug
20 710905 1 Seeger ring I11
21 710258 1 O Ring 5/612 Parker
22 710822 1 Valve piston
24 710916 2 O Ring 2/15 Parker
25 710841 1 Coil
26 710853 1 Clamps return springs
27B 710823 3 Casing
28B 710921 3 O Ring 2/115 Parker
29B 710840 1 Valve spacer
31 720811 1 Tool body
32 710350 1 O Ring 2/109 Parker
33 711304 1 Silencer 1/4
34 710906 1 Hermetic washer 400-820
35 710839 1 Oil tank plug
38 710909 1 Connector 2023
41 710838 1 Out put connector
42 710824 1 Push-button
43 710919 1 O Ring 2/4 Parker
44 710847 1 Valve body
45 710528 2 O Ring 008 D
46 710848 1 Valve piston
47 710918 1 O Ring 2/5 Parker
48 710385 4 O Ring 006 D
49 710842 1 Suction adjustement knob
50 720812 1 Handgrip
54 710816 1 Oil-dynamic cylinder
55 717004 1 Nozzle for rivet ø 4,8 Cu/Steel
56 710843 1 Head carrying nozzle
57 710859 1 Clamps holding cone
58 71345507 3 High-performance clamps
710011 3 Standard clamps
59 710849 1 Clamps opener
60E 710819 1 Nails container
61G 710834 1 Suction tube
62 710102 1 O Ring 113 D
63G 710858 1 Cone holder
64G 710832 1 Expeller extension
65 710854 1 Balancer hook
66 710917 1 O Ring 2/118 Parker
67 710855 1 Sleeving gasket
68 710577 1 Balsele B086055
69 710908 1 Flat washer Al. 14x22x1,5
70C 711973 1 Seeger ring AV16
71C 710845 1 Stop ring
72 710901 1 Balsele B102070
73C 710821 1 Anti-extrusion ring
74 712281 1 Piston
75D 710852 1 Interior spring reversal piston
76D 710851 1 Exterior spring reversal piston
77 710850 1 Plug guide spring
78 710818 1 Container connector
79 717006 1 Nozzle for rivet ø 2,4
Revision - 09

SPARE PARTS

DESCRIPTION
Date 03-2010
GB
KIT No. CODE Q.ty
80 717001 1
81 717002 1
A 82 717003 1
83 717005 1
84 721387 1
A 85 711092 1
86B 711158 1
A 87E 711136 1
88 711305 1
89F 710186 1
90F 711401 1
95 711974 1
96 711736 1
97 712162 1
98 710831 1
99 712117 1
100 712133 1
B
B
B
No. CODE Q.ty
KIT A 740837
4A 710837 1
7A 710836 1
9A 710829 1
KIT B 740840
27B 710823 3
28B 710921 3
29B 710840 1
86B 711158 1
KIT C 740821
70C 711973 1
71C 710845 1
73C 710821 1
KIT D 740851
75D 710852 1
76D 710851 1
E
G
KIT E 740819
60E 710819 1
G
87E 711136 1
G
KIT F 741401
89F 710186 2
90F 711401 2
KIT G 740858
C
61G 710834 1
C
63G 710858 1
64G 710832 1
C
D
D
KIT
DESCRIPTION
Nozzle for rivet ø 2,4÷3,4
Nozzle for rivet ø 4
Nozzle for rivet ø 4,8 Al.
Nozzle for rivet ø 6÷6,4
Oil container
Key 5mm
Spring
Air conveyor
Connector 1631/01 - 1/4
O Ring 010 D
Bush
Seeger ring JV22
Protection bottom
Outside silencer protection
Tube Ø 8x7
Washer stopping spring
Rotating connector
KIT
DESCRIPTION
Screw stem kit
Screw stem
Flat washer
Dampener
Valve spacer kit
Casing
O Ring 2/115 Parker
Valve spacer
Spring
Anti-extrusion ring kit
Seeger ring AV16
Stop ring
Anti-extrusion ring
Spring reversal piston Kit
Interior spring reversal piston
Exterior spring reversal piston
Nails container kit
Nails container
Air conveyor
Bush kit
O Ring 010 D
Bush
Cone holder kit
Suction tube
Cone holder
Expeller extension
It indicates that the part is sold in kits consisting of different
parts in different quantities.
KIT
B
E
F
F
33
