Activate Password Protection
MENU
KEY
PERSON
In the menu KEY the password protection of the fixture is activated or deactivated. If set ON the
fixture is password protected when started. 30 seconds after the last setting the menu is locked
again. To be able to make changes in the menu the password UP - DOWN - UP - DOWN - ENTER
needs to be typed in.
Whiteadjustment
MENU
PERSON CALIB.C
In the menu CALIB.C the whiteadjustments can be set.
In the submenu WHITE the preset colour temperatures for the white values are stored.
Info Menu
MENU
INFO
PERSON
In the info menu (INFO), submenu VERSION the currently installed firmware version is shown.
In the submenu RDM, submenu UID the RDM-ID and in the submenu LABEL the model name of the
fixture can be found.
HSIC ON
HSIC OFF
WHITE WH.01
WH.02
o
o
o
WH.13
VERSION V01
RDM UID
LABEL
E-28
2700K
3000K
o
o
o
10000K
3503Axxxxxxxxx
****
LED PROFILE XAL
****
