Setting DMX-Address
MENU
PERSON ADDRESS
The DMX start address of the fixture is set in the menu ADDRESS. This is retained even when
changing the personality.
Setting DMX-Personality
MENU
PERSONALITY PERSON
The personality is set in the menu PERSONALITY. There are four different modes which can be
choosen: HSIC (10 channels), SIMPLE (6 channels), SDO (8 channels), COLOR 8BIT (11 channels)
and COLOR 16BIT (17 channels).
Edit Static Colours
MENU
PERSON STATIC
Static colours for stand-alone operation are set in STAT. These are mixed using the DMX value scale
0-255 for RED, GREEN, BLUE, AMBER, LIME as well as the strobe value 0-20Hz STROBE.
Using Preset Colours
MENU
PRESET COLOR PERSON
In the menu PRESET COLOR the preset colours stored in the device are activated.These are based
on the colour scale of some Lee and Rosco filters (LXXX/RXX).
D.(001 - 512)
HSIC
HSIC
SIMPLE
SDO
COLOR 8BIT
COLOR 16BIT
R.(0 - 255)
HSIC RED
G.(0 - 255)
GREEN
B.(0 - 255)
HSIC BLUE
A.(0 - 255)
HSIC AMBER
L.(0 - 255)
HSIC LIME
S.(0 - 20)
HSIC STROBE
HSIC L106
HSIC R05
HSIC L194
HSIC R54
HSIC L019
HSIC R08
HSIC R89
HSIC R86
HSIC L213
HSIC R377
HSIC R80
HSIC L202
HSIC L328
HSIC R3314
HSIC L101
HSIC L768
