Technical data

Base units
Installation method
Insert positions for single or twin modules
Input data
Input frequency range
Input splitter terr./sat
Connection loss (per 4-way splitter) terr./sat
Through loss (per 4-way splitter)
Remote feeding for LNB supply
Output data
Output frequency range
Output coupler
Connection loss
Operating output level
Power supply unit
Mains voltage
Max. power consumption
Secondary voltage/max. permissible current
Overload indication (red LED) (max. permissible secondary power)
General
Fans
Volumetric fl ow per fan
Max. power consumption of fans
Ambient temperature range
Dimensions (W x H x D)
Packaging unit/weight
)
¹ The additional UFZ 412 wall mounting kit is available for wall mounting
² ) Extendable with UFZ 300

Installation

Installation procedure:
1. Fit the base unit and make potential equalisation
connections to the regulations (DIN EN 50083-1/
DIN EN 60065)
2. Connect the input splitters to the Sat-IF drop cables
(H and V) in accordance with the system diagram
(F connector). For this, if necessary remove the HF
connection cables between the splitters and change
over the terminating resistors
3. Connect the output cable to the base unit output
(F connector)
4. Remove the HF and power cables from the assembly
clips and remove the assembly clips (these can be used
for fi xing the installation cables)
Type
Order no.
MHz
dB
Terr.
dB
Sat
V/mA
MHz
dB
3)
PAL
64 QAM
dBµV
256 QAM
FM
V/Hz
W
A
W
m 3 /h
W
°C
mm
pc./kg
3)
The operating output level of the UFO 394 is about 4 dB lower
UFG 412
20610090
Installation in 19" rack cabinet and wall mounting ¹
12
87.5-862/950-2150
3 x 4-way ²
16
2.5
3.5
18/max. 600
5-862
3 x 4-way on 1 x 3-way
Type 14
81
71
77
77
207-253/47-63
250
5 V/14.5
12.5 V/10.0
18 V/0.6
31 V/0.11
212
2
100
2 x 13
-20 to +50
483 x 408 x 265/350
1/12.5
483
UFG 412/R
20610091
)
)
270
1/15.0
