2 Operating instructions
The parameter currently selected with the buttons
The setting of the desired value occurs stepwise via the buttons
(see section 4).
Select or exit a sub-menu using the
On the display, the symbol
If the controller is disconnected from the UFO
the settings originally stored in the module are reactivated.
Note:
The module-specifi c setting instructions are included with the instructions for the respective UFO
Note:
The instructions include stickers with button explanations in English, French and Spanish.
These can be applied over the German stickers on the back of the device.
3 Direct input of alphanumeric values for a parameter
Press the button
Selection of the values assigned to a button occurs serially by pressing the button briefl y several times
The selection series always begins with the number
Pressing the button moves the cursor to the left
By pressing the button again, the direct input mode is exited and the input value is loaded

Installation and safety instructions

•
The equipment described is designed solely for the installation of satellite receiver systems.
• Any other use, or failure to comply with these instructions, will result in voiding of warranty cover.
• The equipment may only be installed in dry indoor areas. Do not mount on or against highly combustible
materials.
• The equipment must be provided with an earthing wire (Cu, at least 4 mm).
• The safety regulations set out in the current EN 60728-11 and EN 60065 standards must be complied with.
• Connector: HF plug 75 Ω (series F) to EN 61169-24.
Current-carrying unit
• Do not open or tamper with the unit!
• When working on the system always unplug the mains plug from the wall socket!
• Ensure adequate clearance! Clearance all round at least 5 cm!
• Do not install overhead.
• Free circulation of air must be possible to discharge the heat emitted by the unit. Risk of overheating!
• Permissible ambient temperature -20 to +50°C
Attention:
• No liquid-fi lled items may be placed on top of the power supply unit or the fans.
• Neither the power supply unit nor the fans may be exposed to dripping or sprayed water.
• The mains plugs for the power supply unit and the fans must be easily accessible and easily disconnected.
• The only reliable method of disconnecting the power supply unit and the fans from the mains is to unplug
them.
• The fans must be supplied via a power socket with a earth conductor.
• The device may not be operated unless the fans are running.
and
button.
blinks if there is a sub-menu available for the selected parameter.
® compact module without saving the settings by pressing the
fl ashes on the display.
and or via the input of alphanumeric characters
Note:
If the unit is wall-mounted, the earthing clip supplied must be
attached with two screws (M4 x 10) and two spring washers.
The mounting can be performed on either the left or right
side of the base unit.
button,
® compact module.
