1
50
Boom Clamp
Pos.
Description
1
Parts from STEP49
2
Nylon Lock Nuts M3
3
Washer 3.2x7x0.8
4
Belt T ensioner Mount
5
Button Head Bolts M3x6
6
Rubberring
7
Guide Wheel Mount Collar
8
Cap Socket Bolt M3x46
9
Cap Socket Bolt M3x44
1 0
Cap Socket Bolt M3x40
11
Boom Clamp
Use medium threadlock on all
screws going into metal parts.
Verwenden Sie auf allen
Schrauben die in Metallteile
geschraubt werden mittelfeste
Schraubensicherung.
2 2
Qty.
Part number
1
4
91-0003
4
82-3708
1
14-1002
2
79-0306
1
14-7092
1
14-2005
1
80-0346
2
80-0344
1
80-0340
2
14-1001
4
3
2 2
3
Mount the rubberring (6) to the belt tensioner and the
belt tensioner mount (4) by using the bolts (5) and the
guide wheel mount collar (7). Now install the bolts (8,
9) with the washers (3) and the lock nuts (2) through
the boom clamp (11).
orientation (the pins (marked red) face to the front
of the heli).
Finally install the rear bolts (9, 10). Put
them through the holes in the belt tensioner mount
(4), the frame and the boom clamps and lock it with
the lock nut (2) and the washers (3).
Montieren Sie den Gummiring (6) an den
Riemenspanner und mit dem Abstandshalter (7) und
den Schrauben (5) an den Riemenspannerträger (4).
Montieren Sie nun die vorderen Schrauben (8, 9) mit
den Scheiben (3) sowie den Stoppmuttern (2) durch
die Klemmschalen (11).
deren Ausrichtung (der Zapfen (hier rot
dargestellt) muss nach vorne montiert werden).
Nun werden die hinteren Schrauben (9, 10) mit dem
Riemenspannerträger (4), den Scheiben (3) und den
Stoppmuttern (2) montiert.
5
7
3
5
0
10
20
30
Take care about there
Achten Sie hierbei auf
1 0
9
9
8
40
6
1
