ENGLISH
Blackout Mode
Blackout mode: when no DMX-signal is detected, the unit goes in blackout and waits for the DMX-
signal.
No blackout mode: when no DMX-signal is detected, the unit automatically switches to standalone
mode.
 Press the MENU button until
 Press the ENTER button, the display starts blinking.
 Use DOWN and UP button to select
 Once the mode has been selected, press the ENTER button to save it.
(or automatically return to the main functions without any change after 8 seconds)
To go back to the functions without any change press the MENU button again for about 2 seconds.
Pan Inversion
Normal: Panning movement is not inversed.
Pan inversion: Panning movement is inversed
 Press the MENU button until
 Press the ENTER button, the display starts blinking.
 Use DOWN and UP button to select
 Once the mode has been selected, press the ENTER button to save it.
(or automatically return to the main functions without any change after 8 seconds)
To go back to the functions without any change press the MENU button again for about 2 seconds.
Tilt Inversion
Normal: Tilt movement is not inversed.
Tilt inversion: tilt movement is inversed
 Press the MENU button until
 Press the ENTER button, the display starts blinking.
 Use DOWN and UP buttons to select
 Once the mode has been selected, press the ENTER button to save it.
(or automatically return to the main functions without any change after 8 seconds)
To go back to the functions without any change press the MENU button again for about 2 seconds.
Led Display
Display on: display is always on.
Display off: display is off when not used.
 Press the MENU button until the display shows
 Press the ENTER button, the display starts blinking.
 Use DOWN and UP buttons to select
 Once the mode has been selected, press the ENTER button to save it.
(or automatically return to the main functions without any change after 8 seconds)
To go back to the functions without any change press the MENU button again for about 2 seconds.
Display Inversion
Display normal: display is readable when the unit is on the floor.
Display inversion: display is readable when the unit is mounted upside down.
 Press the MENU button until
 Press the ENTER button to toggle between
 After about 8 seconds your choice is automatically saved.
Focus Adjust
Used to help you adjusting the focus of the light beam and gobos.
 Press the MENU button until
 Press the ENTER button so the unit goes to the "tilt 90°" position.
JB SYSTEMS
®
is shown on the display.
(blackout on) or
is shown on the display.
(normal) or
is shown on the display.
(normal) or
.
(display always on) or
is shown on the display. (normal display)
(normal display) and
is blinking on the display.
6/77
OPERATION MANUAL
(blackout off) mode.
(pan inversion) mode.
(tilt inversion) mode.
(display off when not used).
(display inversion).
LED CLUBHEAD
