f. Showtime... almost!
Engine break-in is the most important step to assuring that your
engine is fast and reliable throughout its life. Put simply: DON'T SKIP
THIS PART!
The engine is pre-set from the factory for break-in. Use a platform and
place the car so that the wheels are off the ground and free.
Make sure the throttle is set at neutral with your radio. Place the glow
heater onto the glow plug and give the recoil a sharp pull (picture 4).
Do not pull it more than twelve inches! More than that may break the
cord and this is not covered under warranty. It is better to give the
recoil short sharp pulls rather than long ones. If the pull-start cord
gets stuck, rotate the flywheel a little bit with your finger. This should
make the cord automatically recoil. Within a few pulls, the engine will
start with a good puff of smoke.
Picture 4
If the engine has trouble idling at the rich setting, turn the idle screw
clockwise 1/8th of a turn at a time. This will increase the idle allowing
the car to break-in properly. Try to do this in a well-ventilated area,
such as your driveway. Unburned oil from the fuel will accumulate
under the exhaust, so be prepared.
Let the car idle like this for 2 - 3 tanks of fuel checking the engine
temperature every 2 minutes. Please allow a break of 10 – 15 minutes
in between filling the tank to allow the engine to cool down. You
should be able to touch the head of the engine with your fingertips
and it will be hot, but not uncomfortably so. (Attention! Do not touch!)
If it seems very hot, richen (turn counter-clockwise) the high-end and
low-end needles 1/8th of a turn. Always use small increments when
making these kinds of adjustments.
Racer Tip:
Factory setting of carburettor:
With the following basic adjustment the engine starts immediately,
running perfect and rich enough:
• Idle stop screw: approx. 1 mm air gap;
• High speed needle valve: screw in completely, then open 4 full
turns;
• Low speed needle valve (linking): flush with the edge of the linking
arm, then 1 full turn clockwise;
Picture 5
rich
Picture 6
rich
After run-in is finished the high speed needle valve should be open at
least 3 and 1⁄4 turns. A richer setup is better if outside temperature is
high.
Racer Tip:
Drive your car slowly with the rich setting shortly after the break-in
period avoiding prolonged periods at full throttle. Gradually lean out
the mixture 1/8 of a turn at a time. The idle will increase the more you
lean the engine out.
