b. Chassis
Motor Body holder
Air filter
Roll bar
Rear shock units
Transmission
Muffler
GB
Receiver box
Rear tyre
On/off switch
Gasservo
Tank
Front tyre

Chassis

Front shock units
c. Plug in Receiver Batteries
Insert 4 "AA" batteries into the receiver battery case as shown
Picture 1
(compare picture 1). Make sure positive (+) and negative (-) ends
are facing the correct direction. Then plug the pack into the switch
harness, inside the radio case. Black goes to black and red goes to red.
Replace the battery case cover.
Racer Tip:
Use rechargeable batteries! They last longer and are cheaper in
the long run. Replace the 4 "AA" car batteries with our NiMh
O
6 V/ 1100 mAh battery pack (N 50 060 8036 JR).
CARSON Raptor Pro V25 19
