EN
RADIAL MITRE SAW
Thank you for buying this Ferm product.
By doing so you now have an excellent product,
delivered by one of Europe's leading suppliers.
All products delivered to you by Ferm are
manufactured according to the highest standards
of performance and safety. As part of our
philosophy we also provide an excellent customer
service, backed by our comprehensive warranty.
We hope you will enjoy using this product for
many years to come.
The numbers in the following text refer to the
pictures on page 2-3
Read the operating instructions
carefully before using this device.
Familiarise yourself with its functions
and basic operation. Service the device
as per the instructions to ensure that it
always func tions properly. The
operating instructions and the
accompanying documentation must be
kept in the vicinity of the device.
Intended use
The electro tool is intended as a stationary
machine for making straight lengthways and
crossways cuts in wood. Horizontal mitre angles
of -45° to +45° as well as vertical bevel angles of
-45° are possible.
Contents

1. Machine information

2. Safety
3. Mounting accessories
4. Operation
5. Service & Maintenance
1. Machine information

Technical specifications

Mains voltage
Capacity
Machine class
No load speed
Saw blade measurement
Angle for mitring
Angle for bevelling
Mitre saw maximum sawing capacity:
Mitre 0º, Bevel 0º
4
230 V, 50Hz
1500 W S6 (25%) / 1400 W S1
II (double insulated)
5000/min
210x30x2.8mm
45º (left and right)
45º (only left)
60x310mm
Mitre 45º, Bevel 45º
Mitre 45º, Bevel 0º
Mitre 0º, Bevel 45º
Weight
L (sound pressure)
pa
L (acoustic capacity)
wa
Vibration level
Vibration level
The vibration emission level stated in this instruction
manual has been measured in accordance with a
standardised test given in EN 61029-1; it may be
used to compare one tool with another and as a
preliminary assessment of exposure to vibration
when using the tool for the applications mentioned
- using the tool for different applications, or with
different or poorly maintainted accessories,
may significantly increase the exposure level
- the times when the tool is switched off or when
it is running but not actually doing the job, may
significantly reduce the exposure level
Protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping your
hands warm, and organizing your work patterns
Package contents
1 Dust adapter
1 Pair of safety glasses
1 Carbon brush set
1 Pair of earplugs
2 Side bars
1 Anti-tip over support
Check the machine, loose parts and accessories
for transport damage.
Features
Figs. 1, 2, 3, 4 and 5
1. On/off switch
2. On/off switch for laser
3. Unlock button (Blade protective cover)
4. Cover carbon brush
5. Lock-pin
6. Blade protective cover
7. Workpiece clamp
8. Guide fence
9. Knob adjusting saw angle
10. Locking knob
11. Locking paddle
12. Knob over sliding support
13. Connection dust bag
35x210mm
60x210mm
35x310mm
15 kg
97+3 dB(A)
110+3 dB(A)
<2.5 m/s
2
