Option: Fresh Water Inlet - ECOLAB Oxy-Gen PLUS Bedienungsanleitung

The metering release takes place either via pulses from a contact water meter in a
consumer pipe or via an external release signal.
• If metering takes place from the
metering console is activated via a flow meter in proportion to volume.
• If metering takes place from the
released via a release signal depending on the measured value.
For details of the requisite settings on the relevant metering pump, please refer to the
metering pump Operating Instructions (metering pump EMP KKS E60
NOTE
417101442 or metering pump EMP II E60
manual for the EMP E60, Art. No. 417101253).
5.4

Option: Fresh water inlet

Constant conditions are required at the fresh water inlet for operating the
fresh water volumetric flow is limited via the needle valve on the
unit.
We recommend the fittings listed below at the fresh water inlet:
Fig. 5.14
Since the dilution of the transporting water is an hydraulic process and is not monitored in
proportion to volume, constant conditions are required at the fresh water inlet in order to
ensure constant generation of chlorine dioxide (see Fig. 5.14)
417101630_OxyGen Plus.doc
Oxy-Gen
PLUS
Oxy-Gen day container to a consumer line, the
PLUS
Oxy-Gen day container to a tank, metering is
PLUS
, Art. No. 417101438, as well as the software
- 77 -
PLUS
PLUS
, Art. No.
Oxy-Gen
PLUS
Oxy-Gen production
Pos. Description
1 Ball valve:
Used as a shut-off organ for
maintenance purposes at the
fresh-water inlet
2 Filter
Used to filter particles and
suspended matter, thereby
avoiding damage to the
components of the
3 Pressure reducer
Used to limit the pressure of the
fresh water to 2 bar
4 System separator
For conformity with the Drinking
Water Ordinance, thereby
avoiding contamination of the
drinking water supply.
PLUS
. The
PLUS
Oxy-Gen
1-04/09
