Busch-Jaeger 6480U-102 Betriebsanleitung Seite 55

Fig. 1
Legend to Fig. 1
Pos. 1:
Pos. 2:
Pos. 3:
Pos. 4:
Pos. 5:
Pos. 6:
Pos. 7:
Pos. 8:
Pos. 9:
Pos. 10:
Display (see also Fig. 2)
<C> = Reset to factory settings
= Extending/ reduce input value
<Enter> = Confirm programming
<Blank button>
<Auto> = Switch between automatic and
manual
<Prog> = Call up or cancel programming
= Retracting/ increase input value
<Free> = Activate/deactivate programming
protection
Control element without cover plate
(see also Fig. 3)
