Turn on the transmitter using the preset model memory and connect the battery. Also connect the
wing cables to the receiver.
22
ARF
PNP
First, as far as possible, adjust all rods mechanically. Then, the control and adjustment of the servo
directions and travel ways as shown in the table below.
24
ARF
PNP
The center of gravity (CG) is 68-72mm behind the leading edge. For beginner-compatible light
behavior, irst set the center of gravity to 68mm by moving the battery. For performance-opti-
mized Hotliner behavior, the center of gravity can slowly be moved further back.
26
Function
Elevator
Rudder
Ailerons
16
Flaps
www.modellmarkt24.ch;
www.modellmarkt24.ch;
Instructions and User Manual
I N S T A L L A T I O N A N D T U N I N G P R O C E S S
C O N T R O L T H R O W S
Normal
Speed
+5 mm / -3 mm; 20% Expo
/
+10 mm / -8 mm; 35% Expo
/
23
25
27
Thermal
www.modellmarkt24.de
www.modellmarkt24.de
ARF
PNP
Mount the wing on the fuselage. Make sure that no
cables are trapped between the fuselage and the
wing!
ARF
PNP
Finally, the servo covers are glued with UHU Por.
PNP
ARF
Later mark the exact position of the CG on the bat-
tery and fuselage, as well as the aileron servo plugs.
Landing
-1 mm
/
+ 15 mm
/
