Congratulations on your purchase of the new LIMIT PRO!
The LIMIT PRO is a high-quality FRP hotliner with a dynamic light envelope.
It can be lown within in a broad speed range. There are various ways of constructing the model, depending
on your preferences.
Therefore the solutions stated in this manual should only be considered as recommendations.
For the most parts, the PNP (plug and play) version is already prefabricated.
The ARF version (almost ready to ly) requires modeling experience and basic technical knowledge in
construction.
Thus there are diferent ways to achieve a model with good light skills.
This is why most alternatives are in fact explained in the manual but not necessary shown in the pictures.
Please read this manual carefully before you start assembling the model.
F L I G H T I N S T R U C T I O N S
Before the irst light, observe the instructions in the „Safety Instructions" section.
•
To ly in the model, you should choose a day with as little wind as possible
•
A large, lat meadow without obstacles (trees, fences power lines etc.) is suitable for the irst lights.
•
Carry out another functional test of the drive and remote control.
•
After assembling the model on the airield, check once again that all model components such as wing,
•
tail units, wing mounts, engine, linkage, etc. are irmly seated.
For the hand start a helper should be present, who can transport the model with not too little thrust
•
into the air.
The start usually takes place against the wind
•
Do not stall the model near the ground
•
Do not initiate tight bends in the immediate vicinity of the ground.
•
Check the reactions of the model to the rudder delections. If necessary, the rashes after landingto
•
increase or decrease the size accordingly.
The minimum light speed must be at an adequate safety altitude.
•
Initiate the landing with suicient speed
•
S A F E T Y I N S T R U C T I O N S F O R B A T T E R I E S
Do not immerse the battery in water or other liquids.
•
Do not heat, throw into ire or microwave.
•
Do not short-circuit or charge with reversed polarity
•
Do not expose, deform or throw the battery to pressure
•
Do not solder directly on the battery
•
Do not change or open the battery
•
Only charge the battery with suitable chargers, never connect it directly to a power supply unit.
•
Never charge or discharge the battery or charger on a lammable surface.
•
Never leave the battery unattended during charging or discharging processes.
•
Never charge or discharge the battery in direct sunlight or near heaters or ire.
•
Do not use the battery in places subject to high static discharge.
•
Keep the battery away from children
•
Do not associate leaked electrolyte with ire, as it is highly lammable and may ignite.
•
The electrolyte liquid should not get into the eyes, if it does, rinse immediately with plenty of clear
•
12
water and then see a doctor.
Observe the safety instructions of the battery manufacturer and the charger manufacturer.
•
www.modellmarkt24.ch;
www.modellmarkt24.ch;
Instructions and User Manual
P R E F A C E
S P E C I F I C A T I O N S
Span
1700 mm
Length
900 mm
Weight (dry)
approx.550 g
Flying weight
approx.1350 g
Wing Area
23,5 dm²
Airfoil
MH-30
C.G.
68 - 72 mm
B O X C O N T E N T / N E E D E D A C C E S S O R I E S
ARF
Motor
not included
ESC
not included
Folding Prop
not included
Spinner
not included
Battery
not included
Servo ELE
not included
Servo RUD
/
Servo AILE
not included
Servo FLAP
/
Servo cable
not included
MULTIlock
/
MPX plugs
/
Adhesives
not included
TX
min. 5 Channels (not included)
RX
min. 7 Channels (not included)
www.modellmarkt24.de
www.modellmarkt24.de
Elevator
yes
Rudder
no
Ailerons
yes
Flaps
no
Flaps
no
Motor
yes
Landing Gear
no
PNP
Robbe X36-800 #5800 (built-in)
not included (RoControl 6-60 #8711)
Aeronaut CAM Prop 12x8" #7234/50 (included)
Alu Turbo Spinner 38mm (included)
not included (ro-Power 4S 3200-4000mAh)
1x Robbe FS-155 MG #9106 (built-in)
/
2x Robbe FS-155 MG #9106 (built-in)
/
2x 20cm (JR), 3x 50cm (JR)
/
/
UHU Por, Epoxy, Thread Locker (n.included)
min. 5 Channels (not included)
min. 7 Channels (not included)
