2. Product description
2.1
General information
AHT products meet the requirements of the EU directive
2011/65/EC (RoHS2) for preventing dangerous substances
from entering electrical and electronic devices and the EU
regulation 1907/2006 (REACH) on registering, assessing
and approving chemicals.
When it came to designing the product, the manufacturer
ensured that the appliances were environmentally friendly
and easy to dispose of. This was especially the case with
the refrigerant propane (R-290) and with pentane, the blow-
ing agent for the insulating foam. Propane has no ozone
depletion potential (ODP) and a very minimal greenhouse
gas potential (GWP) of 3.
2.2
Technical specifications
The important technical specifications are found on the rat-
➙
ing plate (see
Chapter 2.2.1).
External dimensions
Airborne noise emission
Maximum load
storage racks
Storage rack
Standard shelf / display
rack (grating)
Bottom plate / bottom shelf
including grating
technical interfaces:
Power supply (appliance-
specific, adhere to the
specifications on the rating
➙
plate, see
Chap. 2.2.1)
with plug types (appliance
connection)
Minimum requirements
for the connection cable:
Minimum cross section
Defrost water outlet
communication
Bus cable
Brine connection:
Dutch connection
light control
(control of external day/
night signal)
347345_1116
➙
See
Model types –
Overview
Emission sound pressure
level < 70 dB(A)
➙
- See
the following
table and Chapter 9.1
- Label inside on the upper
right of the appliance ceil-
ing, next to the rating plate.
Max. load [kg/m²]
115
600
- 3 x 380-420V 50Hz /N/P
CEE 5x16A
or
- 3-pole, 4-wire ground
208-240 V/ 60 Hz
NEMA L15-20P
2.5 mm² (14AWG)
DN 40
AHT Inter Cabinet BUS
(ICB)
CAT 5-S/FTP (PIN 1-8 al-
located)
3/4"
(supply/return)
Potential-free contact
Electrical fuse protection (see chapter 7.2):
All combinations must have a 3-pole circuit breaker.
Circuit
Nominal
breaker
current [A]
for
for
208-
380-
240V
420V
MCB
20
16
(LS)
RCCB
≥ 40
≥ 40
(FI)
RCBO
20
16
(FI-LS)
If you need further information, please contact maintenance
➙
services (see
Chapter 10.4).
Subject to technical modifications.
2.2.1
Rating plate and serial number
Please refer to the information on the rating plate when
handling the appliance. The rating plate can be found as a
label on the upper right of the appliance ceiling. It contains
important technical specifications, including:
∙
Appliance designation and appliance type
∙
Serial number
➙
∙
Climate class (see
Chapter 2.3)
∙
Nominal voltage and nominal frequency
∙
Nominal current and nominal consumption
∙
Refrigerant and amount employed
∙
Net volume
∙
Manufacturing date
∙
Test mark
∙
Technical specifications for interior lighting (optional)
∙
And other technical specifications
2.3
Intended use
The appliance is only suitable for the storage of packaged
frozen food products.
NOTICE
Property damage due to improper use.
▶ Do not operate the appliance above the conditions
specified in the climate class (ambient temperature,
relative air humidity).
▶ The ambient temperature must never fall below
16°C (60.8°F).
Do not operate the appliance above the climate class
specified on the rating plate (see
additional label.
The climate class is specified on the rating plate (see
Chapter 2.2.1) or the additional label on the appliance.
Trip
Type
Re-
charac-
sidual
teristic
current
[mA]
C
_
_
(delay)
G (surge
30
_
current
strength)
C
G (surge
30
(delay)
current
strength)
➙
Chapter 2.2.1) or the
➙
