CLEANING AND MAINTENANCE

We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use
alcohol or solvents!
There are no serviceable parts inside the device except for the fuse. Maintenance and service operations are
only to be carried out by authorized dealers.

Replacing the fuse

If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Open the fuse-holder on the rear panel with a fitting screwdriver.
Step 2: Remove the old fuse from the fuse-holder.
Step 3: Install the new fuse in the fuse-holder.
Step 4: Replace the fuse-holder in the housing.
Should you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by a special power supply
cable available at your dealer.
Should you have further questions, please contact your dealer.

TECHNICAL SPECIFICATIONS

Power supply:
Power consumption:
Number of DMX channels:
DMX512 connection:
Sound-control:
Maximum ambient temperature T
Maximum housing temperature T
Min. distance from flammable surfaces:
Min. distance to lighted object:
Fuse:
LED type:
Number of LEDs:
Beam angle:
Dimensions (LxWxH):
Weight:
Accessories:
TPC-10 Coupler, silver
AG-5 3x600mm Safety bond up to 5kg
XLR cable 3pin 3m bk
XLR plug 3pin 110 Ohm
IEC extension 3x1.0 1m
SB-18 Soft bag
Please note: All information is subject to change without prior notice. 22.10.2015 ©
DANGER TO LIFE!
Disconnect from mains before starting maintenance operation!
:
a
(steady state):
C
100-240 V AC, 50/60 Hz ~
63 W
5/6/8
3-pin XLR
via built-in microphone
45° C
73° C
0.5 m
0.1 m
F 1 A, 250 V
10 W QCL
7
21°
110 x 210 x 220 mm
1.4 kg
No.
59006856
58010360
3022047N
30208430
30235200
30130555
24/24 00089853.DOC, Version 1.1
