Installing the Flight Battery

1. Lower the throttle.
2. Power on the transmitter.
3. Center the throttle trim.
4. Attach hook material to the quadcopter frame and loop
material to the battery.
5. Install the flight battery on the quadcopter frame. Secure the
flight battery with a hook and loop strap. Connect the battery
cable to the ESC, noting correct polarity.
6. Do not move the quadcopter until the receiver initializes.
7. The quadcopter motor will emit initialization tones, indicating
the ESC is armed.
CAUTION: Always disconnect the Li-Po battery from the quadcopter receiver when not flying to avoid over-
discharging the battery. Batteries discharged to a voltage lower than the lowest approved voltage may
become damaged, resulting in loss of performance and potential fire when batteries are charged.
CAUTION: Connecting the battery to the ESC with reversed polarity will cause damage to the ESC, the battery
or both. Damage caused by incorrectly connecting the battery is not covered under warranty.

Transmitter and Receiver Binding

To bind or re-bind your quadcopter to your chosen transmitter, please follow the directions below.
General Binding Procedure
1. Disconnect the flight battery from the quadcopter.
2. Select a clean model memory on your transmitter (computer radios only).
3. Select Acro or Airplane model type on your transmitter.
4. Make sure all servo reversing is set correctly for your radio. Refer to the Transmitter Setup Table.
5. Center all trims on your transmitter.
6. Power off the transmitter and move all switches to the 0 position. Move the throttle to the low/off position.
7. Connect the flight battery in the quadcopter.
8. Put the transmitter into bind mode while powering on the transmitter.
9. Release the bind button/switch after 2–3 seconds.
10. Disconnect the flight battery and power the transmitter off.
CAUTION: When using a Futaba
the throttle channel and re-bind. Refer to your Spektrum module manual for binding and failsafe instructions.
Refer to your Futaba transmitter manual for instructions on reversing the throttle channel.
If you encounter problems, obey binding instructions and refer to the troubleshooting guide for other instructions.
If needed, contact the appropriate Horizon Product Support office. For a list of compatible DSM
please visit www.bindnfly.com.
transmitter with a Spektrum™ DSM2
®
7
/DSMX module, you must reverse
® ®
transmitters,
®
