ISOMETER® IR426-D47
Klimaklassen nach IEC 60721:
Ortsfester Einsatz (IEC 60721-3-3) (ohne Betauung und Eisbildung)....................................... 3K5
Transport (IEC 60721-3-2) (ohne Betauung und Eisbildung) ................................................... 2K3
Langzeitlagerung (IEC 60721-3-1) (ohne Betauung und Eisbildung)...................................... 1K4
Mechanische Beanspruchung nach IEC 60721:
Ortsfester Einsatz (IEC 60721-3-3) .......................................................................................... 3M4
Transport (IEC 60721-3-2) ....................................................................................................... 2M2
Langzeitlagerung (IEC 60721-3-1) .......................................................................................... 1M3
Anschluss ............................................................................................................. Schraubklemmen
Anschlussvermögen:
Starr / flexibel .............................................................. 0,2...4 / 0,2...2,5 mm
Mehrleiteranschluss (2 Leiter gleichen Querschnitts):
Starr / flexibel ...................................................................................... 0,2...1,5 / 0,2...1,5 mm
Abisolierlänge.................................................................................................................. 8...9 mm
Anzugsdrehmoment ................................................................................................. 0,5...0,6 Nm
Anschluss .................................................................................................................. Federklemmen
Anschlussvermögen:
Starr ............................................................................................ 0,2...2,5 mm2 ( AWG 24...14)
Flexibel ohne Aderendhülse ..................................................... 0,75...2,5 mm2 (AWG 19...14)
Flexibel mit Aderendhülse ......................................................... 0,2...1,5 mm2 ( AWG 24...16)
Abisolierlänge........................................................................................................................ 10 mm
Öffnungskraft ............................................................................................................................ 50 N
Testöffnung, Durchmesser ................................................................................................... 2,1 mm
Sonstiges
Betriebsart..................................................................................................................... Dauerbetrieb
Einbaulage ............................................................................................................................ beliebig
Schutzart, Einbauten (DIN EN 60529) ....................................................................................... IP30
Schutzart, Klemmen (DIN EN 60529) ........................................................................................ IP20
Gehäusematerial.......................................................................................................... Polycarbonat
Entflammbarkeitsklasse .................................................................................................... UL94 V-0
Schnellbefestigung auf Hutprofilschiene......................................................................... IEC 60715
Schraubbefestigung ................................................................................... 2 x M4 mit Montageclip
Software-Version ........................................................................................................... D276 V1.2x
Gewicht .............................................................................................................................. ca. 150 g
Bestellangaben
Typ / Versorgungsspg. U
Type Supply voltage U
IR426-D47-2 AC/DC 70...300 V, 15...460 Hz
Montageclip für Schraubmontage (1 Stück je Gerät, Zubehör)/Mounting clip for screw fixing (1 piece per device, accessories)
**Absolutwerte des Spannungsbereichs
Alle Rechte vorbehalten.
Nachdruck und Vervielfältigung
nur mit Genehmigung des Herausgebers.
Änderungen vorbehalten!
©
Bender GmbH & Co. KG
Bender GmbH & Co. KG
•
Londorfer Str. 65 35305 Grünberg
•
Postfach 1161 35301 Grünberg
8
2
(AWG 24...12)
**/ Nennspg. U
s
** Nominal voltage U
s
AC/DC 0...132 V, 42...62 Hz
•
Germany
•
Germany
Climatic categories acc. to IEC 60721:
Stationary use (IEC 60721-3-3) (except condensation and formation of ice) ......................... 3K5
Transport (IEC 60721-3-2) (except condensation and formation of ice) ................................. 2K3
Storage (IEC 60721-3-1) (except condensation and formation of ice) .................................... 1K4
Classification of mechanical conditions acc. to IEC 60721:
Stationary use (IEC 60721-3-3) .................................................................................................3M4
Transport (IEC 60721-3-2) .........................................................................................................2M2
Storage (IEC 60721-3-1) ............................................................................................................1M3
Connection............................................................................................................... screw terminals
Connection properties:
Rigid / flexible ............................................................. 0.2...4 / 0.2...2.5 mm
Two conductors with the same cross section:
2
Rigid / flexible....................................................................................... 0.2...1.5 / 0.2...1.5 mm
Stripping length .............................................................................................................. 8...9 mm
Tightening torque, terminal screws .......................................................................... 0.5...0.6 Nm
Connection........................................................................................................ push-wire terminals
Connection properties:
Rigid ............................................................................................ 0.2...2.5 mm2 ( AWG 24...14)
Flexible without ferrules............................................................ 0.75...2.5 mm2 ( AWG 19...14)
Flexible with ferrules.................................................................. 0.2...1.5 mm2 ( AWG 24...16)
Stripping length .................................................................................................................... 10 mm
Opening force ............................................................................................................................. 50 N
Test opening, diameter ........................................................................................................ 2.1 mm
Other details
Operating mode .............................................................................................................. continuous
Position .......................................................................................................................... any position
Degree of protection internal components (EN 60529) ........................................................... IP30
Degree of protection terminals (EN 60529) ............................................................................. IP20
Enclosure material ....................................................................................................... polycarbonat
Flammability class.............................................................................................................. UL94 V-0
DIN rail mounting acc. to .................................................................................................. IEC 60715
Screw fixing ............................................................................................ 2 x M4 with mounting clip
Software version ............................................................................................................ D276 V1.2x
Weight ......................................................................................................................... approx. 150 g
Ordering details
/ Art.-Nr. Schraubklemme/
n
Art. No. scre terminal
n
B91016307
**absolute value of the voltage range
Tel.: +49 6401 807-0
Fax: +49 6401 807-259
Art.-Nr. Federklemme/
Art. No. push-wire terminal
B71016307
B98060008
All rights reserved.
Reprinting and duplicating
only with permission of the publisher.
Subject to change!
©
Bender GmbH & Co. KG
E-Mail: info@bender.de
Web: http://www.bender.de
IR426-D47_D00040_03_M_DEEN/07.2017
2
(AWG 24...12)
2
