Control unit

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16 -18 RJ 11 socket
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
Table 2
125_WL_Buch.indb 25
Power supply 8-36 VAC
or 9-40 VDC
GND
Input signal 1
GND
Input signal 2
GND
Input signal 3
GND
Input signal 4
TxD
RxD
GND
ISP
GND
123456
NO (open)
NC (closed)
COM
NO
NC
COM
NO
NC
COM
NO
NC
COM
TTL1
TTL2
D: RS485B
C: RS485A
B: GND
A: +5V
Wall terminal Dialock - status: 12.2008 - 732.29.125
Mounting and Operating Instructions
Serial interface RS 232
FLASH Program mode
Can be used in place of connection
11,12,13
Connection:
2: TxD
3: RxD
4: not connected
5: GND
Relay 1
Relay 2
Relay 3
Relay 4
Digital output 1 (open collector)
Digital output 2 (open collector)
Serial interface to reader unit
and voltage supply for
reader unit
25
