3.3. Adding remote controls

3.3.1. 2- or 4-button remote controls
Copying the function from a memorised button on a 2- or 4-button remote
control to a button on a new 2- or 4-button remote control:
A
Remote control "A" = "source" remote control already memorised
Remote control "B" = "target" remote control to be memorised
For example, if the button on remote control A opens the gate fully, the
button on the new remote control (B) will also open the gate fully.
3.3.2. 3-button remote controls
Copying the function from a memorised button on a 3-button remote con-
trol to a new 3-button remote control:
A
2s
For example, if remote control A operates the gate's remote lighting, the
new remote control (B) will also operate the gate's remote lighting.
4. MAINTENANCE
4.1. Checks
4.1.1. Safety devices (cells, safety edge)
Check for correct operation every 6 months.
4.1.2. Backup battery
For optimum battery life, it is recommended that the main power supply be
switched off and the motor operated using the battery for several cycles,
three times a year. Contact a qualified person (installer) to have the backup
battery replaced.

4.2. Replacing the battery

4.2.1. Keytis RTS
4
A
B
B
< 1s
4.2.2. Keygo RTS

5. TECHNICAL DATA

Power supply
Max. power consumption
Climatic operating conditions
Radio frequency
Number of memorisable chan-
nels
Remote lighting output
CONTROL BOX 3S RTS
220-230 V - 50/60Hz
800 W (with 500 W remote lighting)
- 20°C/+ 60°C - IP 44
433.42 MHz
< 10 mW
40
230 V - 500 W (Halogen or incan-
descent only)
