3.1 Replacing the cup head
To replace the cup head, pull it upwards and off. The other push-fi t attachments (see Chapter 6, Ordering
Information) can then be inserted.
4. Maintenance
No routine or extraordinary maintenance is necessary apart from periodic cleaning. In compliance with
the product guarantee law, repairs to the unit must be carried out in our factory, unless previously agreed
otherwise with local distributors (see Warranty, Chapter 7).
4.1 Cleaning
Disconnect the unit from the power supply and use a cloth dampened with an non-infl ammable non-
aggressive detergent.
5. Specifi cations
Speed range
Speed setting
Speed control
Operating temperature range
Operation modes
Type of movement
Maximum load
Construction materials
Power
Power supply
Safety
Weight
Dimensions (WxDxH)
Technical specifi cations subject to change without notice.
6
0 – 3000 rpm
Analogue
Electronic
5 ºC to 40 ºC (max. humidity 80%)
Two: sensor or continuous
Orbital (4.5 mm Ø)
0.5 kg
Unit: Zinc alloy die cast and technopolymer. Cup head: SEBS
Foamed attachments: PE. Feet: MQ/MVQ. Control panel: PET
15 W
Input: AC 100–240 V, 50–60 Hz, 0.5 A. Output: DC 12 V, 1.25 A
Electronic protection degree IP 42-EN 60529. Pollution degree 2-EN61010-1
2.2 kg
180 x 220 x 70 mm
Vortex IR
