Pin configuration

yellow -
white -
pink -
grey -
red -
blue -
brown -
green -
I
white
Pt100
Power supply
brown
I
White and yellow, as well as brown and green can be
exchanged.
We recommed that the earth connection for the
power supply and the output signal be
connected separately.
Max. cable length is 30m. The usual relationship
concerning the evaluation of the voltage signal is to be
observed.
Pt100
Pt100
signal +
signal GND
UB +
UB GND
Pt100
Pt100
yellow
-
U
Meas.
branch
U
green
