TZIDC, TZIDC-110, TZIDC-120 DIGITALER STELLUNGSREGLER | 42/18-84-DE REV. F
... 2 Einsatz in explosionsgefährdeten Bereichen
... TZIDC-110 – Ex-relevante technische Daten
FM / CSA
CSA International
Certificate
Certificate
Class 2258 04
PROCESS CONTROL EQUIPMENT – Intrinsically Safe,
Class 2258 02
Class I, Div 2, Groups A, B, C and D;
Class II, Div 2, Groups E, F, and G,
Class III, Enclosure Type 4X:
Electrical data
Model TZIDC-110, P/N V18346-x032x2xx0x Intelligent Positioner
Input rated
Intrinsically safe with entity parameters of:
Terminals 11 / 12
Terminals 85 / 86
Terminals 41 / 42
Terminals 51 / 52
When installed per installation Drawing No 901265
Temperature code
Max. Ambient temperature
Note
•
The 'x' in P/N denotes minor mechanical variations or
optional features.
•
Local communication interface (LCI) shall not be used in
hazardous location.
•
Each pair of conductors of each intrinsic safety circuit shall
be shielded.
•
Siehe FM installation drawing No. 901265 auf Seite 68.
1649904 (LR 20312)
Entity – For Hazardous Locations
PROCESS CONTROL EQUIPMENT
–For Hazardous Locations
32 V DC; max. 15 mA
(powered by a SELV circuit)
U
= 24 V
C
= 2.8 nF
max.
i
I
= 250 mA
L
= 7.2 uH
max.
i
U
= 30 V
C
= 3.8 nF
max.
i
I
= 50 mA
L
= 0 uH
max.
i
U
= 16 V
C
= 60 nF
max.
i
I
= 20 mA
L
= 100 uH
max.
i
U
= 16 V
C
= 60 nF
max.
i
I
= 20 mA
L
= 100 uH
max.
i
85 °C
CSA certification record
Certificate
Certificate
Class 2258 04
Class I, Div 1, Groups A, B, C and D
Class II, Div 1, Groups E, F, and G
Class III, Div 1, Enclosure Type 4X
Electrical data
Model TZIDC-110, P/N V18346-x032x2xx0x Intelligent Positioner
Input rated
Intrinsically safe with entity parameters of:
Terminals 11 / 12
Terminals 85 / 86
Terminals 41 / 42
When installed per installation Drawing No 901265
Temperature code
Max. ambient temperature
Note
•
The 'x' in P/N denotes minor mechanical variations or
optional features.
T4
•
Local communication interface (LCI) shall not be used in
hazardous location.
•
Each pair of conductors of each intrinsic safety circuit shall
be shielded.
•
Siehe FM installation drawing No. 901265 auf Seite 68.
1649904 (LR 20312)
PROCESS CONTROL EQUIPMENT
– Intrinsically Safe, Entity
– For Hazardous Locations
32 V DC; max. 15 mA
(powered by a SELV Circuit)
U
= 24 V
C
= 2.8 nF
max.
i
I
= 250 mA
L
= 7.2 uH
max.
i
U
= 30 V
C
= 3.8 nF
max.
i
I
= 50 mA
L
= 0 uH
max.
i
U
= 16 V
C
= 60 nF
max.
i
I
= 20 mA
L
= 100 uH
max.
i
T4
85 °C
