4 Identification
4.1 Product description and type
designation
Camera Full HD 1080p, 30x (4.3-129mm), 60fps
4.2 Product marking
See the label attached to the product.
5 Preparing the product for
use
Any change that is not expressly approved
by the manufacturer will invalidate the
guarantee.
5.1 Unpacking
When the product is delivered, make sure that the
package is intact and that there are no signs that it
has been dropped or scratched.
If there are obvious signs of damage, contact the
supplier immediately.
Keep the packaging in case you need to send the
product for repairs.
5.2 Contents
Check the contents to make sure they correspond
with the list of materials as below:
• Camera
• Power cable
• Network cable
• Bolts and screws
• Instruction manual
2
5.3 Safely disposing of packaging
material
The packaging material can all be recycled. The
installer technician will be responsible for separating
the material for disposal, and in any case for
compliance with the legislation in force where the
device is to be used.
When returning a faulty product we recommend
using the original packaging for shipping.

6 Product Overview

• J16: Power connector.
• J17: Ethernet Connector
• 01: Marking label
• 02: Threaded fastening holes
• 03: Camera lens
01
J17
J16
Fig. 1

7 Installation

This product can only be installed on the
ULISSE2 line Pan & Tilt. For installation and
setting please refer to the P&T manual.
03
02
