6. Product information

6.2.2 Alpha Colonne with internal controller

The controller is installed in the lifting column.
The lifting column is traversed using a manual control switch.
The manual control switch is connected directly to the lifting column.
An additional lifting column can be connected to the free socket and both lifting columns can be
traversed individually or parallel using the respective hand switch (no synchronisation).
Alpha Colonne
with internal controller
(Main drive)
48
Manual control switch
6 buttons
e.g. Alpha Colonne
(Auxiliary drive)
