2. Now push the connecting cable of the solar panel through the
hole with 16 mm diameter and into the front box element.
3. Remove the carrier foil from the adhesive strip.
4. Now carefully push the solar panel into the drilled holes with
4 mm diameter.
Connect the VC260 as follows:
Note
Ensure that there is optimal radio reception.
Check the direction of rotation of the tubular drive.
Should the direction of rotation be incorrect, swap
connecting wires 3 and 4 on the tubular drive.

Wiring

1
2
2
3
4
3
4
1
