6 • USE OF THE KINETEC HYGIENIC PADS
The KINETEC HYGIENIC pads are designed for rapid fitting, optimal hygiene and maximum patient comfort.
- For using and positioning the straps, please refer to drawing number 6. Make sure that the self-adhesive parts (18) are visibl
- Place the sponge side next to the skin.
FOR OPTIMAL HYGIENE, A NEW SET OF PADS SHOULD BE USED FOR EACH PATIENT.
Each cover is provided with a label to record the patient's name.
CLEANING:
- The cover can be autoclaved at 125°C (225°F).
- The straps and the foot pad are machine-washable (30°C, 90°F) with chlorine bleach.
Part number to order the complete set : 4650001058
7 • SETTING UP THE PATIENT
- Make sure all knobs are tight.
- Place the KINETEC Optima machine in a position that will be comfortable for the patient.
- Measure in cm or inches the length of the patient's femur (L); adjust the thigh support to this measurement using knob (19).
- To install the patient on the KINETEC Optima machine, push the foot plate (C) up to the patient and tighten the knob (20).
IMPORTANT
Adjust the axis of the patient's hip (21) with the axis rotation (22) of the KINETEC Optima machine, and the axis of the patient's
knee (23) with the axis rotation (24) of the KINETEC Optima machine.
8 • POSITIONING THE FOOT PLATE
The articulated foot plate allows the positioning of the foot from 40° of PLANTAR FLEXION to 30° of DORSIFLEXION and the
leg in 30° of EXTERNAL or INTERNAL ROTATION.
- The knob (25) allows positioning the foot in plantar flexion or dorsiflexion.
- The knob (26) allows positioning the leg in external or internal rotation.
9 • MAINTENANCE
After 2,000 hours of working time, the KINETEC Optima machine needs to be lubricated (joints, ball bearing and threaded rod).
The message SERVICE !! on the hand control when the power on indicates that the service interval has been reached.
You can continue use your KINETEC machine by pressing the START key, but you must contact your KINETEC specialist to
undertake this maintenance operation.
10 • BREAKDOWN
• If you need a spare parts catalogue and/or service manual, please request it from your KINETEC distributor.
• If, after connecting the power cord on the KINETEC Optima machine and switching the machine ON (2),
the display indicates no information:
- Try another electric device to make sure that the power supply is uninterrupted.
- Change the fuse of the socket (27) using a fuse of the same type and value: 2 fuses T 500 mA 250V (6.3x32mm).
- If the display does not indicate any information after following these steps, contact your KINETEC specialist.
• If, after switching on the power to the KINETEC Optima using the switch (2), your machine fails to operate and the display
indicates 15 STOP 25 115, press the START key once again.
If your machine still fails to operate, contact your KINETEC specialist.
• If any of the following messages persists after switching the machine off and pressing the START key,
contact your KINETEC specialist:
- SERVICE D1 (failure of measuring angle)
- SERVICE D2 (failure during motion)
- SERVICE D3 (failure of motor direction)
11 • CLEANING
First, switch the CPM unit OFF and disconnect the power cord from the receptacle.
Spray a DISINFECTANT product (i.e., PROPANOL/ISOPROPANOL or ALDEHYDE solution) on to the SURFACES (plastic
leg support, plastic covers and metal parts).
To clean the KINETEC hygienic pads, please refer to paragraph 6.
12 • SYMBOLS
TYPE B EQUIPMENT
(insulated against electric shock)
WARNING
(consult accompanying documents)
OFF (disconnected from the mains)
ON (connected to the mains)
Hand control lock
Hand control unlock
Stimulator
13 • GUARANTEE LIMITS
The KINETEC guarantee is strictly limited to free replacement or to repair
of the part or parts acknowledged as defective, at the Smith & Nephew fac-
tory.
Smith & Nephew Kinetec guarantees its passive motion device against any
manufacturing defect for 1 year from the date of purchase by the consumer.
Smith & Nephew Kinetec alone is qualified to judge whether the guarantee
applies to the specific problem.
The guarantee connot be applied if the apparatus has been subjected to ab-
normal use or has been used in circumstances other than those stipulated
in our user manual.
The guarantee will not be applied in case of deterioration or accident due to
negligence, lack of supervision or maintenance or an attempt to repair the
equipment.
Flexion
14 • ACCESSORIES
14.1 Plastic leg support
14.2 Bed straps
Extension
14.3 Wheels
14.4 Carrying handle
e.
14.5 Clamp for the foot-end of the bed
14.6 PT table clamp attachment
14.7 Cart
