WARRANTY
According to legal regulations, the warranty-period for this unit is 12 months
(proved by original invoice) for material and manufacturing defaults.
We do not take any liability for damages caused by a non-accurate unit.
Before starting to work, always carry out the Accuracy Check
according to the corresponding chapter.
This warranty is no longer valid if the unit is opened or the labels are
removed.
TECHNICAL DATA
Leveling accuracy
Rotation:
Operational area
Laser type:
Laser class:
Self-leveling range:
Leveling time:
Leveling indicators:
Laser beam diameter
Power supply:
Operating temp.:
Storage temp.:
Tripod attachments:
Measurements/Weight:
Low voltage indication:
Low voltage disconnection:
1) at 21° Celsius
2) under optimal atmospheric circumstances
www.kreitel-vermessungsgeraete.de
3) along the axis
DECLARATION OF CONFORMITY
We
Spectra Precision Kaiserslautern GmbH
Am Sportplatz 5
D-67661 Kaiserslautern
declare under our sole responsibility that the product
QL-150/1452GC
to which this declaration relates is in conformity with the following standards
EN 61000-4-2, 1994; EN 55022, 1994; EN 61000-4-3, 1997
following the provisions of directive
Electromagnetic compatibility 89/336/EEC.
This is to certify that the construction laser (S/N Page 50) complies with the
specifications mentioned in the operating manual when leaving our facilities.
All instruments are controlled on a 100%-basis; the individual datas are
kept in our files.
The managing director
14
1,3
:
< ± 31"; ± 0.15 mm/m
appr. 550
1,2
:
appr. 660 feet (200 m) with detector
red diode laser 635 -670 nm
1 mW , class 2
appr. ± 8% (appr. ± 4,8°)
appr. 30 sec
2 LEDs; laser blinks
1
:
appr. 5 mm
4 x 1.5V Baby cells type C (LR14)
-4°F...122°F (-20°C ... 50°C)
-4°F...158°F (-20°C ... 70°C)
5/8"
248 x 182 x 184 mm / 2,1 kg
blinking of the power on LED
no laser beam
1
/min.
Operating Manual
