POS. DESCRIPTION
9
Screw
10
Mooring rope puller
11
Spring for pressure lever
12
Mooring rope puller pin
13
Pressure lever
14
Screw
15
Rope/chain stripper "AS"
16A
Chain guide cover
16B
Chain guide cover - stainless steel SPMSGG10ASCX
17A
Base Aster in chrome-plated bronze SGMSC08ASC00
17B
Base Aster in stainless steel
18
Plug
19
Gasket / jig Aster
20
Sensor
21
Circlip
22
Bearing
23
Flange
24
Shaft 300/500W
25
Long shaft 300/500W
26
Key
27
Key
28
Stud
29
Gearbox flange gasket
300/500W
30A
Gearbox 500W Quick series
30B
Gearbox "Hi Speed" 500W
Quick series
31
Washer
32
Spring washer
33
Nut
34
Screw
35
Geared motor seal
36A
Key
36B
Electric motor 300W 12V
36C
Electric motor 500W 12V
37
Electric motor 500W 24V
38
Flange gasket
39
Motor casing watertight 300/500W PCCCPM040000
40
Poles gasket
electric motor 300/500W
41
Bottom protec cover
electric motor 300/500W
42
Screw
ASTER / ASTERX 300/500W - REV007A
CODE
MBV0410MXTSC
MMSTTC08ASC0
Quick
MMTND08ASC00
marine environments. In any case, any salt deposits on the outside
MMTC08ASC000
must be removed periodically to avoid corrosion and damage to
PDLVTD08ASCN
the equipment. The parts where salt may have built up should be
MBV0512MXCE0
washed thoroughly with fresh water.
MSN10ASX0000
SGMSGG08ASC1
Once a year, the drum and the gypsy are to be taken apart as fol-
lows:
DRUM VERSION
SPMSC10ASCX0
Use the handle (1) to loosen the bush (2); pull off the drum (3) and
MSR08XASC000
the top clutch cone (5); loosen the fixing screws (14) of the rope/
PGBSG10AS000
chain stripper (15) and remove it. Pull off the gypsy (6).
KNREEDCL0000
NO-DRUM VERSION
MBAE3015Y000
Use the handle (1) to remove the gypsy cover (4); remove the top
MBJ160060000
clutch cone (5); loosen the fixing screws (14) of the rope/chain
MSVFLPRAS000
stripper (15) and remove it and pull off the gypsy (6).
MSAS05206R00
MSAS05245R00
Clean all the parts removed to avoid corrosion, and grease the shaft
MBH0606050X0
thread (24 and 25) and the gypsy (6) where the clutch cones rest (5
and 7).
MBH0606020X0
MBP080608X00
Remove any oxide deposits from the terminals of the electric motor
PGFLRDTG4000
and the reversing contactor unit; grease them.
SLMR05TG4000
SLMR05TG40HS
MBR08X000000
MBR08XDE0000
MBD08MXEN000
MBV0516MXE00
PGBMR0400000
MBH040415F00
EMF031200000
EMF051200000
EMF052400000
PGGPMFN04000
PGGPMPM04000
PCCPPMFN0400
MBV03916AXCC
MAINTENANCE
WARNING: make sure the electrical power to the motor
is switched off when working manually on the windlass.
Carefully remove the chain or rope from the gypsy or the
rope from the drum.
®
windlasses are manufactured with materials resistant to
GB
17
