Extron COMMANDER 3 Bauanleitung Seite 11

Fahrwerk / INSTALLING MAIN GEAR
Es gibt zwei Möglichkeiten
There are two options:
Starres Fahrwerk / MAIN GEAR STRUTS
1.
Elektrisches Einziehfahrwerk / ELECTRIC GEAR RETRACTS
2.
Einziehfahrwerk (optional) / Retracts are optional
Bestell-Nummer = X8986
Order No.
3pcs.
Starres Serienfahrwerk / Fixed landing gear is standard
Nose gear electric Nose gear
Art.-Nr. / Item-No. X8981/X8982
Manual Commander 3.indd 11
Landing gear mount.
75mm Wheels
65mm Wheels
Main gear
www.extron-modellbau.de
3x15mm Tp Screw Wheel Collar
- - - - 12
Plastic Collar 4x4mm Setscrew
- - - - - - - - 3
4x4mm
Collar
Collar
Nose gear
- - - - - - - - 3
- - - - - - - - 3
Screw
Main gear
11
