Attachment parts for pressure device
2 Allen screws M6 x 12 (for square below)
2 Plastic cap screws M6 x 20
4 Carriage bolts M6 x 35
4 Plastic cap nuts M6
4 Washers 6mm
Assembling the pressure device:
Insert the 2 square bolts (H) in the 2 square tubes
provided and secure them with the 2 Allen screws.
Attach the 2 clamps (I) on the 2 square bolts (H) us-
ing the 2 plastic cap screws.
Then push the 2 square mounting plates (G) through
the 2 openings of the 2 clamps (I).
Finally, attach the pressure frames (F) to the square
mounting plates using the 4 carriage bolts, the 4
washers and the 4 plastic nuts.
Fitting the moulding fence onto the working ta-
ble, Fig. 8–11
The installation of the shaping stop collar is done as
follows:
Fix the 2 plastic cap screws to the grooves in the
moulding fence using the washers (Fig. 9).
Put the tops of the plastic cap screws through the
opening in the table grooves (Fig. 10).
Position the moulding fence as required and tighten
the plastic cap nuts (Fig. 11).
Kickback safety fence components
1 Kickback safety fence
1 Mounting bracket
Attachment parts for kickback safety fence
2 Recessed head screws M5 x 10
2 Washers 5mm
2 Circlips 5mm
2 Carriage bolts M6 x 25
2 Washers 6mm
2 Wing nuts M6
Fitting the return kick safety fence
• Locate the two holes at the centre of the machine
front (Fig. 12).
• Then align the mounting bracket to the two holes
(Fig. 13).
• Insert the two bolts and their washers into the
holes, then tighten them firmly with a four-way
socket wrench.
• After that, install the fence in such a way that it
can slide and be adjusted to the thickness of the
work piece.
• After setting, fix it with the help of the two bolts
(Fig. 14).
Fitting the working depth
For setting or reducing the spindle height (serves for
height-adjustment of the cutting knives), turn the han-
dle (see figure 23, 6) in order to reduce or increase
the height, as required.
Secure the setting by tightening the clamping screw
(7).
22 GB
For your safety, with most jobs it is urgently recom-
mended to use the cutter head with the smallest
height in relation to the table top.
Attachment parts for table extension:
8 Allen screws M5 x 20
6 Allen screws M5 x 12
8 Washers 5mm, small
6 Washers 5mm, large
8 Hexagonal nuts M5
14 Circlips 5mm
Fitting the table width extensions, Fig. 2, 2.1, 11
and 12
The table width extensions enlarge the table surface,
thus allowing the handling of larger work pieces and
the execution of special moulding jobs.
Attach the extension table on both sides with 4 Allen
screws M5 x 20, 4 washers, 4 circlips and 4 hexago-
nal nuts M5 each and on the face of the table with 3
Allen screws M5 x 20, 3 washers and 3 circlips each.
Align the table and tighten all screws.
Connection of a dust extractor unit to your spin-
dle moulder
The connection facility for an external dust extractor
unit or system for the elimination of dust and chips
(not supplied) is provided.
Slide the suction hose of the dust extractor unit onto
the suction connection piece at the rear of the mould-
ing fence. For hoses with a dia. of 100 mm, a conical
adapter is found in the packing.

Putting into operation

Attention: The spindle moulder has an axle that is
placed in a vertical manner onto the horizontal table.
The axle serves for the acceptance of the moulding
tools, discs and formed cutters. The spindle moulder
is used for producing friezes, simple or manifold re-
cesses, grooves, rebates, profiles and counter pro-
files on straight surfaces, etc.
With the spindle moulder, in no way cutter heads of
a larger diameter than 50 mm must be used. If larger
diameters are required, we recommend working at
several steps and the repeated adjusting with the use
of the height setting knob, or the step by step setting
of the fence.
1. Installing and changing the clamping sleeves
for top spindle moulders (Fig. 17, 14)
• Before changing the clamping sleeves, pull the
power supply plug of your machine. Select the
clamping sleeve matching the diameter of your
cutter head.
• Remove the reducing piece from the table open-
ing, Fig. 15.
• Lock the spindle with the button at the bottom of
the spindle, Fig. 17.
• Release the safety nut of the clamping sleeve us-
ing the key supplied, Fig. 16.
