MANUFACTURER:
scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D-89335 Ichenhausen
DEAR CUSTOMER,
We wish you much pleasure and success when
working with your new scheppach machine.
NOTE:
The manufacturer of this equipment is not, accord-
ing to the valid product liability law, responsible for
damage caused on this equipment or caused by this
equipment:
• inappropriate treatment,
• neglect of the operating instructions,
• repairs through third, unauthorized specialists,
• installation and exchange of non-original spare
parts,
• unintended use,
• Losses in the electrical system due to neglect of
the electrical regulations and VDE regulations
0100, DIN 57113/ VDE0113.
We recommend that you:
Read the entire text of the operating instructions be-
fore assembling and before start-up.
These operating instructions are to enable you to
become acquainted with your machine and your in-
tended application type.
The operating instructions contain important notes,
such as how to work with the machine safely, profes-
sionally and economically, and how to avoid hazards,
save repair costs, reduce down-time and increase
the reliability and life-span of the machine.
In addition to the safety regulations in these operat-
ing instructions, you must absolutely consider the
regulations of your country which are valid for the
function of the machine.
Retain the operating instructions in a plastic cover
protected against dirt and humidity, and on the ma-
chine. Each operator must read and follow them
carefully before taking on work. Only people who are
instructed and informed in the use of the machine
and the associated dangers are allowed to work on
this machine. The demanded minimum age is to be
adhered to.
Apart from the safety instructions contained in these
operating instructions and the special regulations
of your country, the technical rules generally recog-
nized for the function of woodworking machines are
also to be followed.
18 GB
General instructions
• After unpacking, examine all parts for possible
transport damage. In case of objections, the sup-
plier must be informed immediately. Later com-
plaints are not recognized.
• Examine the transmission for completeness.
• Become familiar with the equipment, on the basis
of the operating instructions, before working.
• Use only original accessories as well as spare
parts. You may obtain spare parts from your
scheppach specialist dealer.
• When ordering our article numbers, please provide
the type and year of construction of the equipment.
Controls and parts, Fig. 1-2
1 bench top
2 milling notice
3
3a stop bar right
3b stop bar left
4 Upper pressure bar
5 Lateral pressure bar
6 Height adjustment
7 clamping screw
8 Cross-cutting jig
9 speed adjustment
10 Circuit breaker
11 Right side table extension
12 Left side table extension
13 Overload switch
Scope of supply
• Vertical spindle moulder hf 50
• 2 table width extensions
• Adjustment crank with cap nut M6
• Tool guard with cylinder pin D 6mm x 35mm
• Mitre gauge, complete
• Allen key 4 mm
• Allen key 5 mm
• Key SW 19
• Key SW 24
• Operating instructions
Technical data
Sizes L/B/T mm
Table size mm
Table height mm
Size table width extension
W D mm
Vertical adjustment mm
Table restrictor inserts
mm
Dimensions workpieces
(LxWxH) max.
Number of revolutions
min
-1
Weight kg
Drive
Motor V/Hz
Acceptance potential
Plug
Technical changes subject to change!
610/360/311
610/630
365
210/360
0–40
32/47/55
650 x 160 x 65 mm
11500 – 24000
23,5
230 - 240~ / 50
1500 W
Schuko
