8. Operating and display elements

The illustrations are located on the fold-out page.
A LED standby
If the device in operatoin, this LED is „green".
B LED „CH 1"
Illuminates as soon as video channel 1 is currently displayed on the monitor.
C „CH 1" key
Press the „CH 1" key in order to display video channel 1 on your display device.
D „Quad" LED
Illuminates if all four video channels are to be displayed at the same time on your display device.
E „CH 2" key
Press the „CH 2" key in order to display video channel 2 on your display device.
F „CH 2" LED
Illuminates as soon as video channel 2 is displayed on the display device.
G "MENU" key
Press this key to switch to the settings mode and back.
H "SET" button
This key is used as a seleection and confirmatoin key.
I „ARM/DISARM" key
Press this key in display mode to enable or disable automatic motion detect.
J „CAPTURE" key
Press this key in display mode to start or end single shot recordings or a video recording.
K „POWER" switch
With this switch you can switch the device on or put it in standby mode.
L „CH 3" LED
Illuminates as soon as video channel 3 is displayed on the display device.
M „CH 3" key
Press the „CH 3" key in order to display video channel 3 on your display device.
N „QUAD" key
Press the „QUAD" key in display mode to display all four video channels (minimised display) on your
display device.
