5

Scope of supply

The scope of supply for the standard equipment includes:
Press device incl. operating manual
Battery charger incl. operating manual
Battery 18 V DC
Optional additional accessories (e.g. press jaws, adaptor jaws, press collars) may also be
included. Please contact the system supplier for information on the scope of supply.
6

Technical data

ACO202XL
Device:
Rated voltage/battery:
Power consumption
Nominal force:
Height:
Length:
Width:
Net weight:
Compression range:
Max. noise level:
Noise pressure level at user's ear:
Vibration value:
Type of protection:
Temperature range during operation:
1) Measurement uncertainty 3 db(A)
The stated vibration emission value was measured using a standard test procedure and can be
employed for the purpose of comparison with another device.
The stated vibration emission value can also be used to obtain an initial estimate of
interruptions during intermittent operation.
Caution: The vibration emission value may differ from the stated value while the device is
actually in use, depending upon the manner in which the device is used. It may be necessary to
establish safety measures to protect operating personnel, depending on the actual conditions of
use (intermittent operation).
ACO202XL
Safety information
Service addresses
Carrying case
ACO202XL
18 V DC (lithium-ion)/1.5 Ah/3.0 Ah
450 W
32 kN
125 mm
515 mm with 1.5 Ah battery
535 mm with 3.0 Ah battery
80 mm
3.85 kg (without battery)
Plastic:
Metal:
87.5 db(A)
76.5 db(A)
<2.5 m/s²
IP20
-10 °C to +50 °C
2) Measurement uncertainty 1.5 m/s²
19
ACO202XL
up to Ø 110 mm
up to Ø 108 mm / 4''
1)
1)
2)
EN
