Varyscan
D1,D2 Bridge
U1 M68HC11F1FN
U2 Eprom 27C256
U3 AM26LS32
U4 PAL22V10
U5 74HC245
U6 no.
U7 PBL3771
U8 PBM3960
U9 PBL3771
U10 PBM3960
U11 TCA3727
U12 74HC574
U13 74HC574
U14 74HC574
U15 TCA3727
U16 TCA3727
U17 LM317
U18 TCA3727
U19 TCA3727
U20 74HC574
U21 74HC574
U22 74HC574
U23 TCA3727
U24 74HC574
U25 74HC574
U26 TCA3727
Y1 Quarz 16MHz
S1 SW DIP-10
S2 SW DIP-4
®
4 1200 HMI
IC DMX-IN
driver x-motor
driver y-motor
driver for goborotation
driver for iris
driver for gobowheel
driver for colour wheel
driver for effect wheel
driver for shutter motor 1
driver for shutter motor 2
DIP-switch No. 1
DIP-switch No. 2
47
