JB-Lighting Varyscan 4 1200HMI Bedienungsanleitung Seite 24

Varyscan
Q1-Q32
P1,P2
JP2
JP3,JP4,JP5 Header4
D1,D2
U1 M68HC11F1FN
U2 Eprom 27C256
U3 AM26LS32
U4 PAL22V10
U5 74HC245
U6 nb
U7 PBL3771
U8 PBM3960
U9 PBL3771
U10 PBM3960
U11 TCA3727
U12 74HC574
U13 74HC574
U14 74HC574
U15 TCA3727
U16 TCA3727
U17 LM317
U18 TCA3727
U19 TCA3727
U20 74HC574
U21 74HC574
U22 74HC574
U23 TCA3727
U24 74HC574
U25 74HC574
U26 TCA3727
Y1 Quarz 16MHz
S1 SW DIP-10
S2 SW DIP-4
®
4 1200 HMI
BC337B
Connector DB15
Header5
Bridge
IC DMX-IN
Treiber X-Motor
Treiber Y-Motor
Treiber Gobodreh
Treiber Iris
Treiber Gobo
Treiber Farbrad
Treiber Effektrad
Treiber Shuttermotor1
Treiber Shuttermotor2
DIP-Schalter NR. 1
DIP-Schalter NR. 2
24
