IMPORTANT
WHEN BAG FULL RED LIGHT SIGNAL (8)
FLASHES,STOP IMMEDIATELY THE LOADING OF
THE CYCLONE.THE MACHINE WILL COMPLETE
THE SHREDDING OF THE MATERIAL IN THE
CHAMBER AND THEN WILL TURN ITSELF OFF FOR
APPROXIMATELY 3 MINUTES TO AVOID ANY
FURTHER INSERTION OF PAPER AND TO ALLOW
THE CHANGE OF THE PLASTIC WASTE BAG.
5

AUTOMATIC FUNCTIONS

(TAV.D-Fig.6)
The KOBRA Cyclone has been equipped with an
electrical panel board which automatically controls the
complete shredding cycle.
By pressing the START button (D) the turbine and the
motor of the vacuum system are turned on.
Simultaneously,are also activated the electrical and
electronic components which control:
THE QUANTITY OF MATERIAL IN THE
o
SHREDDING CHAMBER.
If material is in the shredding chamber, the
Cyclone will continue to operate.
If the Cyclone detects that all material has been
shredded and the shredding chamber is empty
automatically the turbine will be turned off after
one minute and after 30 more seconds also the
motor of the vacuum system will turn off.
THE AUTOMATIC SAFETY STOP IN CASE OF
o
OPENING OF THE SHREDDING CHAMBER
which turns the Cyclone into its stand-by position
until the shredding chamber door is closed.
THE AUTOMATIC ELECTRONIC BAG FULL
o
SENSORS which operates as following:
- When red light (8) [TAV.E-Fig3] flashes,stop
immediately the loading of the machine with the
material to shred.
- Let the Cyclone complete the shredding cycle
and wait until it switches automatically into its
stand-by position.
- The Cyclone now cannot be activated for
approximately 3 minutes in order to allow the
time necessary to change the plastic waste bag.
- When plastic waste bag is replaced,the
red light (8) turns off and the Cyclone can be
started again by pressing the START button (D)
IMPORTANT: EVERYTIME THE RED LIGHT (8)
BLIMPS A COMPLETE BAG FULL SEQUENCE IS
ACTIVATED ( FIRST: COMPLETE THE SHREDDING
OF MATERIAL.SECOND: STAND BY POSITION FOR
THREE MINUTES).
6 CONTROL PANEL BOARD
(TAV.D-Fig.6)
The panel board, conveniently located in the front of the
Cyclone, includes:
AN EMERGENCY SWITCH (A) which is equipped
o
with a lock.In case of any emergency just press the
red button (A) and immediately the turbine and the
vacuum system motor will turn off.
The emergency button can be re-set with its
special key.
The lock of the emergency button allows also the
use of the Cyclone only to selected people through
its special key.
STAND-BY SIGNAL (B) indicates when the
o
Cyclone is ready to be started and connected to
the main power supply (Main switch (U) in position
"I")
YELLOW LIGHT (9) TAV.E FIG.3
o
Lits up when filter bag (s) is full and needs to be
changed
LOAD METER(C) indicates the actual load on the
o
turbine and on the blades of the Cyclone and
shows the availble shredding capacity of the
machine during continuous shredding operations.
LOAD METER green area= 100% capacity(500 sheets)
LOAD METER yellow area= 50% capacity(200 sheets)
LOAD METER red area=no shredding capacity,no
loading of material
START BUTTON (GREEN) (D) When stand by
o
light signal is on,pressing the start button activates
the turbine and the vacuum system motors
STOP BUTTON (RED) (E) Pressing the stop
o
button turns immediately off the turbine motor while
the vacuum system motor will stop after 30
seconds
BAG FULL SENSOR (V) [Tav.F –Fig. 10]
o
This system has been designed to stop the
machine when the plastic waste bag is full.
(A light signal shows the operator when the bag is
full).
CONTROL PANEL BOARD
o
The control panel board is directly wired to the
main electrical board located behind the front
plastic enclosure (S) of the Cyclone [TAV.E-Fig.4]
The components of the main electrical panel board
are tuned and set at the factory to meet the a.m.
operating sequences.
29 di 55 DI-129/06/30.03.12
