8 MAINTENANCE & LUBRICATION
8.2

ENGINE ACCESS ________________________________________________________________

The Fuel & Hydraulic Tanks can be raised for better access
to the engine.
a. Tilt the seat forwards.
b. Turn fuel tap OFF (C) (Gasoline machines only)
c. Loosen the locking handwheel (A), under the tank
above the rear axle.
d. Raise the tanks.
Support the tanks by pivoting the stay (B) beneath the tank
and secure in the hole provided.
WARNING
DO NOT remove the fuel tank cap while the tank
is in the raised position.
CAUTION
When raising the tanks have a second person
available to locate the stay in the hole provided.
8.3

ENGINE OIL LEVEL - GASOLINE____________________________________________________

Damage to engines due to improper maintenance or use of
incorrect oil quality and/or viscosity is not covered by the
engine warranty (refer to the engine operator's manual for
crankcase capacity and recommended oil grade and
weight).
Unit must be on a level surface to obtain an accurate oil
level reading.
The oil level must be kept between the two marks on the
dipstick.
NOTE: DO NOT overfill. Engine overheating and damage may result.
en-50
B
Lifting The Tank
A
C
