BASETech 2002C Original Bedienungsanleitung Seite 23

1 Adjustment wheel for rope pull of the chain brake
2 Hand lever for fastening the saw chain (chain brake)
3 Handle to swivel the grinding unit
4 On-/off switch („I" = on, „O" = off)
5 Cover of the grinding disc (can be removed to replace the grinding disc)
6 Grinding disc
7 Setting screw for limiting the grinding depth
8 Fastening wheel for setting screw (7)
9 Setting screw for chain stopper
10 Fastening wheel for setting screw (9)
11 Chain stopper
12 Setting screw for chain brake
13 Rotary wheel for moving on the saw chain
14 Angle scale
15 Fastening wheel for chain disc
16 Turning chain disc with attached saw blade guide
17 Rotary wheel for moving on the saw chain
18 Opening for table mounting (a second opening is visible on the left, not displayed)
19 Chain brake
The displayed saw chain only serves illustration purposes; it is not contained in the delivery.
