Manual settings and monitoring FeVac Two
4.5

Programming message routing zones

14
LINE1 NORMAL
K1 CHOICHE K2 CHANGE
Press Key T1 repeatedly to switch from Line 1 to 6.
Press Key T2 repeatedly to switch between NORMAL (standard setting), WIDE and SMALL (larger amount
of loudspeakers). (accuracy window)
Press the RESET key twice to return to the initial menu.
This mode is used to determine to which amplifier zones ALARM and ALERT messages or the signals from
the emergency microphone or the external input of the FeVac One are routed when alarm switches 1 to
8 of the FeVac One system are activated.
Note: This MENU is specially protected to avoid the consequences of operating mistakes. Only pressing
the following keys in the sequence indicated below will yield the desired next menu.
**** FEVAC 2 ****
SYSTEM XX : OK
Press the MENU key to display the following menu:
STATUS VERSION
KEY1 KEY2
Press the MENU key 3 times.
ZONE SPECIAL
KEY1 KEY2
Press Key T1.
3x
