The following menu will appear:
ALARM 1
Z1 Z2 Z3 Z4 Z5 Z6
As shown in this display, alarm messages will be sent to all 6 zones when the FeVac
1 is activated. (FeVac Two will not revert automatically to the initial menu if no further key is pressed
within 10 seconds. To return to the initial menu, press the Reset key.)
Scrolling and activation or deactivation of the individual zones:
ALARM 1
Z1 Z2 Z3 Z4 Z5 Z6
Press Key T2 repeatedly to mark successive zones in turn. The zone selected at any given moment is
indicated by a blinking cursor.
ALARM 1
Z1 Z2 . . Z4 Z5 Z6
The zone marked can now be activated or deactivated by pressing the MENU key. If, for example, zone 3
was marked, deactivation yields the display showed above. The characters ".." now replace Z 3. If the
FeVac One alarm switch 1 is now activated, alarm signals are not sent to zone 3 in the FeVac Two
system, but are sent to zones 1, 2 and 4,5,6.
ALERT 1
. . . . Z3 . . . . . .
Press Key T1 repeatedly to lead to the following sequence of displays, in which the activation or
deactivation of zones is indicated as in the previous example.
Manual settings and monitoring FeVac Two
One alarm switch
®
