| Type label

3 Type label
Before calling your service representative, make a note of the specification and production number from the type label,
which can be found on the side of the units, next to the external connections.
Position Description
1
Product code (product specification)
2
Product item number
3
Production order number
4
Serial number
5
Production date (YY.MM.DD)
3.1

QR code

QR code is an optical label that contains the list of spare parts and documentation. The QR code label can be found next
to the type label.
Use a mobile application or any other QR code reader to access its contents.
4

Product description

The SAVE VSR 150/B is a heat recovery ventilation unit with two built in rotating heat exchangers. The SAVE VSR 150/B
is suitable for houses with up to 100 m
tract air from bathroom, kitchen and wet rooms.
SAVE VSR 150/B is equipped with a 500 W electrical re-heater battery.
5

SAVECair control

5.1

General

SAVECair is a modern touchscreen LCD control panel, simply known as HMI — Human Machine Interface. The
touchscreen display provides information about current state of the unit and allows you to control all system functions.
Fig. 1 Type label
Fig. 2 Example of QR code label
heated living area. It supplies filtered outdoor air to residential areas and ex-
