7. Charging Lithium Chemistry (LiPo/Li-lon/LiFe) Type Batteries

This program is only suitable for charging/discharging
Lithium chemistry batteries. The X4 AC Plus was designed
to only charge three kinds of Lithium batteries, Lithium Fer-
rite (LiFe), Lithium Ion (Li-lon) and Lithium Polymer (LiPo).
It is very important that you determine the type of battery
you are charging and set the charging parameters correctly.
Lithium Ion (Li-Ion)
Nominal Voltage Level:
Max. Charge Voltage:
Allowable Fast Charge Current:
Min. Discharge Voltage Cut Off Level:
Lithium Polymer (Li-Po)
Nominal Voltage Level:
Max. Charge Voltage:
Allowable Fast Charge Current:
Min. Discharge Voltage Cut Off Level:
Lithium Ferrite (LIFe)
Nominal Voltage Level:
Max. Charge Voltage:
Allowable Fast Charge Current:
Min. Discharge Voltage Cut Off Level:
When you want to change the settings, press the „START/ENTER" key to make it blink, then use the „DEC"
or „INC" key to change the setting. Then press the „START/ENTER" key again to store the setting.
It is important that the nominal voltage, fi nal voltage, and
battery capacity be properly set for desired operation.
Please refer to the following information regarding the
different types of Lithium chemistry batteries.
3.6 V per cell
4.1 V per cell
1 C or less
2.5 V per cell or higher
3.7 V per cell
4.2 V per cell
1 C or less
3.0 V per cell or higher
3.3 V per cell
3.6 V per cell
4 C or less
2.0 V per cell or higher
