2.3. Charger Layout
Battery Sockets
AC Input Power Port
100-120 V AC (US Version)
220-240 V AC (EU Version)
Universal Balancing
Port Pitch = 2.54 mm
Battery Sockets
Universal Balancing
Port Pitch = 2.54 mm
32
Temp. Sensor/PC Link
Available for output 1&3 only
Temp. Sensor/PC Link
Available for output 2&4 only
Professional Balance Charger, Discharger
Battery Sockets
DC Input Sockets
Battery Sockets
Ventilation Fan with
Temperature Sensor Control
