Professional Balance Charger, Discharger
2.2. Specifi cations
Power Source
Operating Voltage Range
Charge Power
Discharger Power
Cell Count
Current Drain for Balancing Lithium
Charge Termination:
Dimensions
Net Weight

2.3. Charger Layout

LCD Screen
100-120 V AC, 12 V DC Car Battery or
11-15 V DC Power Supply
DC 11-15Volt
50 Watts, current is regulated accordingly
e.g. 11.1 V battery, charge current approx. 4.5 A
e.g. 22.2 V battery, charge current approx. 2.2 A
5 Watts, current is regulated accordingly
1-15 NiCd/NiMH cells
1-6 LiPo/Lilon/LiFe cells
1-10 Lead-Acid cells (2 V-20 V)
300 mA
NiCd/NiMH Automatic, negative delta-peak method
Lead-Acid and Lithium Automatic, voltage-dependent, CC-CV process
8.9" x 6.7" x 2.6"
3.4 Ibs.
LCD Screen
Menu Control Buttons
Menu Control Buttons
