3.2 Ventilation

Observe the required minimum distances for proper ventilation.
M
INIMUM DISTANCES REQUIRED FOR PROPER VENTILATION
Back ↔ wall
Sides ↔ wall
Free space above

Fig. similar: The figure above serves as an example only.
The following minimum distances are recommended by the manufacturer to ensure
Back ↔ wall
Right / left ↔ any piece of furniture / wall
Free space above
These minimum distances may be less, but to do so can increase the power
consumption of the appliance.

3.2.2 Spacers

Depending on model, the appliance is supplied
with two plastic spacers. After installation of these
spacers, the appliance cannot be pushed against the
wall to maintain proper ventilation. Insert the
spacers into the relevant openings on the back of
the appliance, then turn by 45
optimum efficiency of the appliance:
0
to the right or left
min. 20 mm
min. 20 mm
min. 100 mm
min. 100 mm
min. 100 mm
min. 300 mm
.
:
42
